RQ260SC
Features 5050 RGBWW SMD LED, High Luminous; ERP Standard Spectrophotometry,Single Bin Supply,Good Color Consistency; “U” Shape Solder Pad Design, easy to soldering, Firm joints and no Solder False; Products Passed CE、RoHS、UL Certification,to Ensure the Quality;
Classification:
Multi-color Flexible Strips Series
联系我们
Description
Product No | LED Color | CRI | LED Qty (pcs/m) |
Voltage (V DC) |
Current (mA/m) |
Power (W/m) |
CCT(K) WL(nm) |
Luminous Flux (LM/m) |
Light Efficiency (Lm/W) |
RQ260SC | Red | --- | 60 | 24 | 180 | 4.3 | 620-625 | 130 | 30 |
Green | --- | 180 | 4.3 | 525-530 | 350 | 80 | |||
Blue | --- | 180 | 4.3 | 465-470 | 90 | 20 | |||
White | ≥80 | 200 | 4.8 | 2700 | 400 | 83 | |||
White | ≥80 | 200 | 4.8 | 6500 | 500 | 104 |
Features Used 2835 SMD LED with High Brightness and Dual Chips; ERP Standard Spectrophotometry,Single Bin Supply,Good Color Consistency; Room Temperature & High Brightness; Products Passed CE、RoHS、UL Certification,to Ensure the Quality; High Efficacy, Efficiency can up to 180LM/W; Widely Applied in High-end Exhibition Cabinets, Cosmetics Display, Shelf props.
Application Suitable in Hotel. Supermarket. Home. Cabinets. Exhibition Shelves . etc.. Used for main , or indirect, or dark groove ,outline, decorative lighting and other purposes. Features Newest ID design. Concise, Beauty and high sense. 5050 SMD LED with double color temperature. Good light-mixing effect. ERP standard spectrophotometry. Good color uniformity. Double-sided pure copper PCB. Low line loss. Sn plating for solder pad and strong anti-oxidation. CE, RoHS, UL compliant. Quality assurance.
Features 5050 RGBWW SMD LED, High Luminous; ERP Standard Spectrophotometry,Single Bin Supply,Good Color Consistency; “U” Shape Solder Pad Design, easy to soldering, Firm joints and no Solder False; Products Passed CE、RoHS、UL Certification,to Ensure the Quality;
