RQ060NA / RQ060NC

Features 5050 RGB SMD LED, High Luminous; ERP Standard Spectrophotometry,Single Bin Supply,Good Color Consistency; “U” Shape Solder Pad Design, easy to soldering, Firm joints and no Solder False; Products Passed CE、RoHS、UL Certification,to Ensure the Quality;

Classification:

Multi-color Flexible Strips Series


联系我们

Description



Product No LED Color LED Qty
(pcs/m)
Voltage
(V  DC)
Current
(mA/m)
Power
(W/m)
WL(nm) Luminous Flux
(LM/m)
Light Efficiency
(Lm/W)
RQ060NA Red 60 12 400 4.8 620-625 130 27
Green 400 4.8 525-530 350 73
Blue 400 4.8 465-470 91 19



Product No LED Color LED Qty
(pcs/m)
Voltage
(V  DC)
Current
(mA/m)
Power
(W/m)
WL(nm) Luminous Flux
(LM/m)
Light Efficiency
(Lm/W)
RQ060NC Red 60 24 200 4.8 620-625 130 27
Green 200 4.8 525-530 350 73
Blue 200 4.8 465-470 90 19

RGQ0K2FC

Features Used 2835 SMD LED with High Brightness and Dual Chips; ERP Standard Spectrophotometry,Single Bin Supply,Good Color Consistency; Room Temperature & High Brightness; Products Passed CE、RoHS、UL Certification,to Ensure the Quality; High Efficacy, Efficiency can up to 180LM/W; Widely Applied in High-end Exhibition Cabinets, Cosmetics Display, Shelf props.

RQ060PC-2

Application Suitable in Hotel. Supermarket. Home. Cabinets. Exhibition Shelves . etc.. Used for main , or indirect, or dark groove ,outline, decorative lighting and other purposes. Features Newest ID design. Concise, Beauty and high sense. 5050 SMD LED with double color temperature. Good light-mixing effect. ERP standard spectrophotometry. Good color uniformity. Double-sided pure copper PCB. Low line loss. Sn plating for solder pad and strong anti-oxidation. CE, RoHS, UL compliant. Quality assurance.

RQ260SC

Features 5050 RGBWW SMD LED, High Luminous; ERP Standard Spectrophotometry,Single Bin Supply,Good Color Consistency; “U” Shape Solder Pad Design, easy to soldering, Firm joints and no Solder False; Products Passed CE、RoHS、UL Certification,to Ensure the Quality;
